Find Shortest Path using Floyd-Warshall Algorithm

This is a fast implementation of Floyd-Warshall algorithm to find the shortest path in a pairwise sense using RcppArmadillo. A logical input is also accepted. The given matrix should contain pairwise distance values \(d_{i,j}\) where \(0\) means there exists no path for node \(i\) and j.

shortestpath(dist)

Arguments

dist

either an \((n\times n)\) matrix or a dist class object.

Value

an \((n\times n)\) matrix containing pairwise shortest path length.

References

Floyd RW (1962). “Algorithm 97: Shortest Path.” Communications of the ACM, 5(6), 345.

Warshall S (1962). “A Theorem on Boolean Matrices.” Journal of the ACM, 9(1), 11--12.

Examples

## simple example : a ring graph
#  edges exist for pairs
A = array(0,c(10,10))
for (i in 1:9){
  A[i,i+1] = 1
  A[i+1,i] = 1
}
A[10,1] <- A[1,10] <- 1

# compute shortest-path and show the matrix
sdA <- shortestpath(A)

# visualize
opar <- par(no.readonly=TRUE)
par(pty="s")
image(sdA, main="shortest path length for a ring graph")

par(opar)
